| Brand Name: | yue lin sen |
| Model Number: | Y2663 |
| MOQ: | 100 pcs |
| Price: | 0.5-20 |
| Payment Terms: | T/T |
| Supply Ability: | 500000pcs |
| Parameter Category | Specification | Details & Options |
|---|---|---|
| Base Material | Alloy | 316L Stainless Steel (UNS S31603). Low carbon content (<0.03%) for superior corrosion resistance |
| Standards | ASTM A276 (Bar), ASTM A479 (Stainless Steel for Machine Parts), ISO 5832-1 (Implants) | |
| Key Properties | Excellent corrosion resistance (Mo content), good mechanical properties, non-magnetic, biocompatible | |
| Material Form & Size | Form | Round Bar (Rod) |
| Diameter Range | Common: 10 mm - 100 mm diameter. Larger diameters available | |
| Long Shaft Machining | Maximum Finished Length | Up to 1500 mm (longer possible with specialized setups) |
| Diameter Tolerance | Standard: ±0.025 mm. Precision: ±0.01 mm. High-Precision: ±0.005 mm | |
| Straightness Tolerance | Achievable: 0.02 mm per 300 mm or better | |
| Surface Finish (Ra) | Turned: 0.8 - 1.6 µm. Ground: 0.2 - 0.4 µm. Polished: < 0.1 µm | |
| Threading/Tapping | Thread Types | Metric (M), Unified (UNC/UNF), Whitworth, Acme, Buttress, Custom |
| Thread Size Range | Internal: M3 to M30. External: M6 to M80 and larger | |
| Thread Quality Class | Metric: 4H, 5H, 6H (internal); 4g, 6g (external) | |
| Threading Method | Thread Milling (Preferred), Tapping, Thread Rolling | |
| Surface Treatment | Standard Finish | Passivation (per ASTM A967) to maximize corrosion resistance |
| Enhanced Finishes | Electropolishing, Bead Blasting | |
| Production Timeline | Prototype/Small Batch | 4 - 8 weeks (depending on complexity) |
| Production Run | 8 - 14 weeks (volume and complexity dependent) |
