| Brand Name: | yue lin sen |
| Model Number: | Y22568 |
| MOQ: | 100 pcs |
| Price: | 0.5-20 |
| Payment Terms: | T/T |
| Supply Ability: | 5000000pcs |
| Category | Parameter | Details / Specification |
|---|---|---|
| Base Material | Alloy Designation | Hastelloy® C-22 / UNS N06022 / W.Nr. 2.4602 |
| Material Standard | Conforms to ASTM B575 (Sheet/Plate), ASTM B574 (Bar) | |
| Key Characteristics | Exceptional resistance to corrosive chemicals, excellent biocompatibility and thermal stability | |
| Machining Capability | Primary Process | Multi-Axis (3+2, 5-Axis) Precision CNC Milling |
| Machining Difficulty | High - requires rigid machine tools, specialized carbide tooling, and optimized parameters | |
| Achievable Geometries | Complex 3D contours, deep cavities, thin ribs (down to ~0.5mm), precision bores, and undercuts | |
| Precision & Tolerances | Standard Dimensional Tolerance | ±0.025 mm (±0.001") on critical machined features |
| High-Precision Tolerance | ±0.0125 mm (±0.0005") achievable for select features | |
| True Positional Tolerance | Within 0.05 mm or better for mating features | |
| Surface & Finish | As-Machined Finish | Typically Ra 0.8 - 1.6 µm (32 - 63 µin) |
| Critical Post-Process | Electropolishing or chemical passivation per ASTM A967 | |
| Post-Process Finish | Electropolishing can achieve Ra < 0.4 µm (16 µin) | |
| Quality Assurance | Material Certification | Full traceability with Mill Test Certificate |
| Inspection | 100% critical dimension verification using CMM | |
| Cleanliness | Post-machining cleaning per medical device protocols | |
| Compliance | Quality System | Manufactured under ISO 13485 compliant Quality Management System |
| Biocompatibility | Material is inherently biocompatible |
